Fine Wire 0.15-0.6mm Tube Brass Annealing Machine With Hot Pot Tinning

Name: Fine Wire 01506mm Tube Brass Annealing Machine With Hot Pot Tinning
Brand: NEWLEAD
Price: 1 USD

Fine Wire 0.15-0.6mm Tube Brass Annealing Machine With Hot Pot Tinning Manufactures

Place of Origin : Jiangsu, China (Mainland)

Brand Name : NEWLEAD

Model Number : 40H

Price : Negotiation

MOQ : 1 Unit/Units

Certification : ISO CE

Supply Ability : 2 set in 60 days

Delivery Time : 60 days

Packaging Details : wood pallet

Usage : Coating

Function : Annealing and Tinning

Inlet : 0.15-0.6mm

Speed : Max 300MPM

Tinning : Hot pot

Lines : 24/32/40

Contact Now

Fine wire 0.15-0.6mm Tube wire annealing machine with hot pot tinning Easy to operate,good annealing heat preservation,save electricity,achieve industry-leading level.

machine type	40H	32H	24H	12H
number of wire (mm)	40	32	24	12
finished wire diameter (mm)	φ0.15-φ0.65mm	φ0.1-φ0.32	φ0.1-φ0.32	φ0.03-φ0.08
tinning speed(MPM)	300	300	300	300
send-out method	hairbrush wire placing
annealing method	tubular annealing
mode if wire receiving	torque motor 1.2-1.5N.M			torque mot or 0.3-0.7N.m
mode of tin-plating	single-furnace hot dip(trans verse plating) mould tin-scraping			single tinning ove n with scrap dies
annealing length	6m	4.5	4.5	2
spooler dimension	PT5-PT25	PT5-PT25	PT5-PT25	PT5
installed thermal power	68	64.5	64.5	24.5
installed dynamic power	12	10	9	3.5
total installed power	78	74.5	73.5	28
traversing control	decelerate motor,loading & unloading unaided traversing			L&R direction traversing
machine dimension	19800L×1600W ×1900H	18500L×1600W ×1900H	17900L× 1600W×1900H	13000LX 1350WX1530H
machine weight	6350	6250	5800	1800
